Rechenfeldgrößen im Atlas


The dimensions of the screen field are entered in the atlas for 37 sites. The resulting screen widths are between 2.35 m and 51.9 m and the screen heights are between 0.8 m and 12.20 m.

© Ecologic Institute 2022 | CC BY 4.0

Print

Rechenfeldgrößen im Atlas

Publication
Citation

Ecologic Institute 2022: Rechenfeldgrößen im Atlas. Infographic published in: Keuneke, Rita; Edith Massmann and Stephan Naumann 2022: Fischschutz- und Fischabstiegsmaßnahmen – Praxisbeispiele im Überblick. Atlas für den Wissenstransfer zu Fischschutz und Fischabstieg. Ingenieurbüro Floecksmühle GmbH, Umweltbundesamt: Aachen, Dessau-Roßlau.

Download infographic!

This infographic shows the dimensions of the screen field, entered in the Atlas of Fish Protection & Downstream Fish, for 37 sites. The resulting screen widths are between 2.35 m and 51.9 m and the screen heights are between 0.8 m and 12.20 m. The infographic is part of a fact sheet on fish protection and downstream fish migration measures.

The infographic is published under a creative commons license CC BY 4.0. That means it can be copied and redistributed in any medium or format and for any purpose as long as appropriate credit to the authors (Ecologic Institute, Ingenieurbüro Floecksmühle) is given.

Contact

More content from this project

Previous Pause Next
Language
German
Credits

Media format: coloured infographic for a digital fact sheet
Copyright: CC BY 4.0
Content: Rita Keuneke, Edith Massmann (Ingenieurbüro Floecksmühle GmbH, Aachen), Stephan Naumann (German Environment Agency)
Graphic design: Jennifer Rahn
